QSMT Pallet-Free Wet-Batch Block Molding and Palletizing Machine
Bricks leave the mold soft and are stacked wet on the spot, so no pallets are needed
The QSMT series is a wet-batch block machine that combines forming and palletizing in one working cycle. It uses a mechanical, electrical, pneumatic and hydraulic control arrangement in which a multi-dimensional automatic judgment program checks conditions and a human-machine interaction system applies adaptive dynamic pressure adjustment. The machine watches its own running state in real time, diagnoses faults, shuts down when needed and shows the suggested remedy on the interface. Two sizes are offered. QSMT500 runs at 39.5 kW with a molding area of 1150 x 560 mm and about 8000 kg of machine weight, while QSMT1000 runs at 57.5 kW with a molding area of 1150 x 1100 mm and about 12000 kg. Both work at 3200 to 4600 vibrations per minute, a molding cycle of 13 to 18 seconds and a nominal pressure of 21 MPa, with a vibratory force of 68 kN and 150 kN. Because bricks are stacked on the spot as they leave the mold, no pallets or boards are used, and loading work drops sharply. The machine suits standard solid bricks, porous bricks and other small unfired blocks, and its compact structure fits both new plants and upgrades of existing halls.
Configured around output, blocks and operating conditions.
Pallet-free forming side that removes the need for pallets and boards in the wet pressing stage, Integrated wet-batch online cross-palletizing, with bricks stacked the moment they leave the mold, Multi-dimensional automatic judgment program with adaptive dynamic pressure adjustment, Real-time status monitoring, automatic fault diagnosis, automatic shutdown and display of solutions, Imported Japanese hydraulic multi-way vector control system for steady response under continuous duty, Compact structure with low noise and energy demand, suitable for new plants and existing hall upgrades
Typical decision factors
What changes the machine price?
Daily capacity
Output target determines machine size, mould cycles and line configuration.
Automation
Pallet handling, cubing, batching and packaging change total project scope.
Block types
Hollow block, paver, interlock and curbstone may require different moulds and handling.
Service scope
Shipping, installation, training and spare parts are quoted by destination.
Forming and Stacking in One Cycle
The QSMT series was built around a single idea: the block machine should not hand wet product over to a separate stacker. Forming and palletizing run as one high-efficiency operating system, so bricks are stacked the moment they leave the mold and the machine works one pallet at a time on the forming side without depending on a supply of pallets or boards. Loading and unloading work falls away, and with it a large share of the labour, handling cost and breakage that come from moving soft green blocks more than once.
Control and Pressure Adjustment
Control combines electrical, pneumatic and hydraulic systems. A multi-dimensional automatic judgment program evaluates the working conditions, and the human-machine interaction system applies adaptive dynamic pressure adjustment so that pressure follows the material rather than a fixed figure. Running status is monitored in real time, faults are diagnosed automatically, the machine shuts itself down when a condition requires it and the interface displays a suggested remedy. The hydraulic multi-way vector control system is an imported Japanese unit, chosen for steady response under continuous production.
Two Models and Their Parameters
QSMT500 and QSMT1000 share the same working principle but differ in scale. QSMT500 has a machine power of 39.5 kW, a weight of about 8000 kg, dimensions of 5800 x 1800 x 2750 mm, a molding area of 1150 x 560 mm and a vibratory force of 68 kN. QSMT1000 has 57.5 kW, about 12000 kg, 6800 x 1800 x 2750 mm, a molding area of 1150 x 1100 mm and 150 kN. Both run at 3200 to 4600 vibrations per minute with a 13 to 18 second molding cycle and 21 MPa nominal pressure, use vibration-press molding and stack wet-batch online in a cross pattern to a height of 1100 mm, which is 10 layers of standard bricks.
Products and Materials
The machine produces standard solid bricks, porous bricks and other small unfired blocks, and it switches between them through the mold rather than through major changes to the machine. It takes a wide range of solid waste materials, which matters to plants working under resource-utilisation rules and to producers who want to cut raw material spending. The compact structure keeps the floor area small, and the low noise and energy demand make the unit easier to place inside an existing hall.
Plants That Should Consider It
Large brick manufacturers looking for pallet-free operation, labour savings and higher efficiency, solid waste processing companies that need a machine suited to recycled material, and traditional pallet-based plants that now want to remove pallets from the forming side. The design is intended for buyers who compare cost per brick over several years, not only the purchase price.
